PowerPlex® 21 System
Multiplex STR System for Human Identification
- Increases discriminatory power and data-sharing possibilities with loci commonly used in US, Europe and Asia
- Optimized protocols for many sample types, including direct amplification from FTA® cards and pretreated non FTA® card punches or swabs
- Rapid cycling technology reduces thermal cycling time up to 2 hours
Catalog Number:
Size
Catalog Number: DC8902
Catalog Number: DC8942
Fast Process and Flexible Protocols
The PowerPlex® 21 System is a multiplex STR system for human identification applications including forensic analysis, relationship testing and research use. The system allows co-amplification and fluorescent detection of 21 loci (20 STR loci and Amelogenin), including D1S1656, D2S1338, D3S1358, D5S818, D6S1043, D7S820, D8S1179, D12S391, D13S317, D16S539, D18S51, D19S433, D21S11, Amelogenin, CSF1PO, FGA, Penta D, Penta E, TH01, TPOX and vWA. The system offers high discrimination with 21 markers for difficult cases and complete data overlap with most existing multiplexes.
The PowerPlex® 21 System increases laboratory productivity and decreases average turnaround time with 90-minute PCR. Laboratories can also save labor and time since the wash step for FTA® cards is eliminated. Simpler protocols are available for swabs and nonFTA card punches as well. The higher inhibitor tolerance of this system benefits challenging casework samples and results in less locus drop-out and reaction failure for higher success rates.
Promega forensic products are manufactured in alignment with the ISO 18385 standard. This standard ensures minimal risk of human DNA contamination for products used to collect, store and analyze biological materials for forensic purposes. Learn more.
Flexibility for Most Sample Types
The PowerPlex® 21 System is designed to work with a variety of sample types, including difficult casework samples and is compatible with direct amplification from FTA® card punches as well as pretreated swabs and Bode Buccal Collector™ device or S&S 903 punches.
Swab from Buccal Samples
Rapid Processing Solutions for PowerPlex®
The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® Fusion, 21, 18D, 16 HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.
Which Product is Right for Me?
Take me to the Product SelectorProtocols
Complete Protocol
Protocolos Rápidos
Specifications
Catalog Number:
Contenido
| Item | Part # | Presentación | Concentración | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
WEN Internal Lane Standard 500 |
DG500A | 1 × 200μl | View Product | |
| PowerPlex® 21 Allelic Ladder Mix | DG247B | 1 × 100μl | ||
| PowerPlex® 21 5X Primer Pair Mix | DK183B | 1 × 1ml | ||
| PowerPlex® 21 5X Master Mix | DP107A | 1 × 1ml | ||
|
Water, Amplification Grade |
DW099A | 5 × 1,250μl | View Product |
SDS
Search for SDSCertificado de Análisis
Use Restrictions
Not For Medical Diagnostic Use.Condiciones de Almacenaje
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-ET, CXR-ET and WEN dyes are proprietary.
Contenido
| Item | Part # | Presentación | Concentración | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 4 × 25μl | 10ng/μl | View Product |
WEN Internal Lane Standard 500 |
DG500A | 4 × 200μl | View Product | |
| PowerPlex® 21 Allelic Ladder Mix | DG247B | 4 × 100μl | ||
| PowerPlex® 21 5X Primer Pair Mix | DK183B | 4 × 1ml | ||
| PowerPlex® 21 5X Master Mix | DP107A | 4 × 1ml | ||
|
Water, Amplification Grade |
DW0991 | 4 × 6,250μl |
SDS
Search for SDSCertificado de Análisis
Use Restrictions
Not For Medical Diagnostic Use.Condiciones de Almacenaje
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-ET, CXR-ET and WEN dyes are proprietary.
